Plant fiber is a thick-walled tissue widely distributed in seed plants. Its cells are slender, sharp at both ends, have thick secondary walls, often have single-grained holes on the walls, and generally have no living protoplasts when mature. Plant fibers play a major mechanical support role in plants.
Plant fiber environmental protection material is made of rice straw, straw, wheat straw, corn stover, cotton stalk, sawdust, bamboo shavings and other crop straws or other plant stems, first made of 10 ~ 200 mesh plant fiber powder, and then made by special technology A new environmentally friendly material that is mixed with raw materials and then molded or injection molded; natural ingredients can reach 60~90%; can be made into disposable catering containers, controlled degradation containers, handicrafts, daily necessities, building boards, industrial packaging, etc. article.
Plant fiber dryer product introduction:
The machine is a through-flow continuous drying equipment for the drying of flakes, strips and granular materials with good gas permeability. It is especially suitable for materials such as dehydrated vegetables and traditional Chinese medicine decoctions with high water content and high temperature. The series of dryers have the advantages of fast drying speed, high evaporation strength and good product quality. The dehydrated cake-like paste material can be dried after being granulated or formed into a rod shape.
Plant fiber dryer performance characteristics:
◎ The air volume, heating temperature, material residence time and feed rate can be adjusted to achieve the best drying effect.
◎The equipment configuration is flexible, and the mesh belt washing system and material cooling system can be used.
◎ Most of the air is recycled, which saves energy.
◎Unique air distribution device makes the hot air distribution more uniform and ensures the consistency of product quality.
◎The heat source can be matched with steam, heat transfer oil, electric or coal-fired (oil) hot blast stove.
Belt dryer transportation and installation:
1. Due to the large size and weight of the equipment, the lifting and transporting should be at the center of gravity to prevent distortion.
2. It is not necessary to put the foot on the installation. When using it alone, it can be placed directly on the ground and corrected for level. In operation, the chain and each rotating part are required to have no jamming.
3. When the two units are connected in series, the front and the back should be connected to each other and level, and the material can be automatically turned over to the second belt to form a tandem production line.
4. Electrical equipment should be installed in accordance with the specified requirements to ensure safety.
5. Before the end of the test, the lubricant should be added to the reducer, chain, transmission bearing and other parts.
Belt dryer Note:
1. Before starting the machine, check whether the power supply wiring of each fan is reliable and the fan is turning correctly.
2. The electrical control box should have a reliable grounding.
3. Whether the motors in the belt mode are normal.
4. The function setting and speed regulation of the frequency conversion system should meet the specified requirements. The inverter should be strictly referred to the instructions to prevent damage.
5. The steering of the mesh belt should be correct. The rotation should be flexible, natural, without card network, jumping, etc., and the mesh belt must not be reversed.
6. Before the heater is inflated, the drain valve on the steam main pipe should be opened, the condensed water in the pipeline should be drained, then the bypass valve should be opened, and the rust impurities in the pipeline should be flushed by the straight steam, and then the bypass can be closed. Valve, at this point let the steam trap start working, and should check whether the heater, steam trap, solenoid valve work properly.
7. Is the spiral discharge direction normal?
8. After turning on the power switch, check whether the electrical components, temperature control, and pulse system dust collector are working properly.
